| Goes' profilation of this bike |
| Little brother of the 520 Max, the Goes 520 offers you the same unbeatable package but in a short wheelbase chassis |
|
General information |
|
Motorcycle name
|
Goes 520 |
|
Year
|
2010 |
|
Category
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
493.0 ccm (30.08 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power
|
32.2 HP (23.5 kW)) @ 7000 RPM |
|
Torque
|
36.0 Nm (3.7 kgf-m or 26.6 ft.lbs) @ 5500 RPM |
|
Compression
|
10.2:1 |
|
Bore x stroke
|
87.5 x 82.0 mm (3.4 x 3.2 inches) |
|
Fuel system
|
Carburettor. Mikuni BSR 36 |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Independent double A-arm, prel |
|
Rear suspension
|
Independent double A-arm, prel |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Physical measures and capacities |
|
Dry weight
|
312.0 kg (687.8 pounds) |
|
Power/weight ratio
|
0.1031 HP/kg |
|
Overall height
|
1230 mm (48.4 inches) |
|
Overall length
|
2120 mm (83.5 inches) |
|
Overall width
|
1170 mm (46.1 inches) |
|
Ground clearance
|
290 mm (11.4 inches) |
|
Wheelbase
|
1290 mm (50.8 inches) |
|
Fuel capacity
|
19.00 litres (5.02 US gallons) |
|
Other specifications |
|
Color options
|
Silver/black |
|
Starter
|
Electric |
|
Comments
|
2WD - 4WD with locking front differential. |
