| Goes' profilation of this bike |
| You are a cruising fan but you always wanted to share it with your body ? The Goes 360 Max was made for you : 2-up design, backrest and comfort will ensure you long and safe ride at an unbeatable price.
|
|
General information |
|
Motorcycle name
|
Goes 360 Max |
|
Model year
|
2009 |
|
Category
|
ATV |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Displacement
|
313.0 ccm (19.10 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
19.3 HP (14.1 kW)) @ 6250 RPM |
|
Torque
|
25.0 Nm (2.5 kgf-m or 18.4 ft.lbs) @ 5000 RPM |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
78.0 x 65.5 mm (3.1 x 2.6 inches) |
|
Fuel system
|
Carburettor. Mikuni VM 26 |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
CDI |
|
Cooling system
|
Liquid |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Automatic |
|
Front suspension
|
Independent double A-arm, preload adjustment |
|
Rear suspension
|
Monoshock swing arm. preload adjustable |
|
Front tire
|
23/7-10 |
|
Rear tire
|
23/10-9 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
234.0 kg (515.9 pounds) |
|
Power/weight ratio
|
0.0825 HP/kg |
|
Overall height
|
1183 mm (46.6 inches) |
|
Overall length
|
1965 mm (77.4 inches) |
|
Overall width
|
1115 mm (43.9 inches) |
|
Ground clearance
|
213 mm (8.4 inches) |
|
Fuel capacity
|
14.00 litres (3.70 US gallons) |
|
Other specifications |
|
Color options
|
Silver, black |
|
Starter
|
Electric |
|
Comments
|
2WD |
