Giantco HY125-3C 20122012 Giantco HY125-3C specifications, pictures, reviews and rating |
![]() 2012 Giantco HY125-3C. Picture credits - Giantco. Submit more pictures. |
|
General information | |
---|---|
Model: | Giantco HY125-3C |
Year: | 2012 |
Category: | Allround |
Rating: | Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
Engine and transmission | |
Displacement: | 124.6 ccm (7.60 cubic inches) |
Engine type: | Single cylinder, four-stroke |
Power: | 9.9 HP (7.2 kW)) @ 8000 RPM |
Torque: | 8.8 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 7500 RPM |
Compression: | 9.0:1 |
Bore x stroke: | 56.6 x 56.6 mm (2.2 x 2.2 inches) |
Valves per cylinder: | 2 |
Fuel system: | Carburettor |
Fuel control: | Overhead Valves (OHV) |
Ignition: | CDI |
Cooling system: | Air |
Gearbox: | 5-speed |
Transmission type, final drive: | Chain |
Chassis, suspension, brakes and wheels | |
Front suspension: | Oil damped telescopic fork |
Rear suspension: | Oil damped coil spring |
Front tyre: | 90/90-18 |
Rear tyre: | 110/90-18 |
Front brakes: | Single disc |
Rear brakes: | Expanding brake (drum brake) |
Physical measures and capacities | |
Dry weight: | 112.0 kg (246.9 pounds) |
Power/weight ratio: | 0.0886 HP/kg |
Overall height: | 1075 mm (42.3 inches) |
Overall length: | 2015 mm (79.3 inches) |
Overall width: | 750 mm (29.5 inches) |
Wheelbase: | 1285 mm (50.6 inches) |
Fuel capacity: | 14.00 litres (3.70 gallons) |
Oil capacity: | 1.00 litres (0.07 quarts) |
Other specifications | |
Starter: | Electric & kick |
Comments: | Hong Kong made bike. |
