General information |
|
Model name
|
GG Quad |
|
Model year
|
2012 |
|
Category
|
ATV |
|
Rating
|
3.5 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
1130.0 ccm (68.95 cubic inches) |
|
Engine type
|
Two cylinder boxer, four-stroke |
|
Power output
|
93.9 HP (68.5 kW)) @ 7250 RPM |
|
Torque
|
98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 5500 RPM |
|
Top speed
|
170.0 km/h (105.6 mph) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Driveline
|
Differential with reverse gear |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Hydraulic shock absorbers with infinitely variable adjustment |
|
Rear suspension
|
Hydraulic shock absorbers with infinitely variable adjustment |
|
Front tire
|
195/40-16 |
|
Rear tire
|
225/35-17 |
|
Front brakes
|
Single disc |
|
Diameter
|
270 mm (10.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
270 mm (10.6 inches) |
|
Wheels
|
Cast aluminium |
|
Physical measures and capacities |
|
Overall length
|
2220 mm (87.4 inches) |
|
Overall width
|
1400 mm (55.1 inches) |
|
Fuel capacity
|
18.00 litres (4.76 US gallons) |
|
