| GAS GAS' profilation of this bike |
| The Racing version of the new EC 2012 is now available. The essence of Enduro has been enhanced with exclusive components and specific adjustments to achieve optimum off-road performance. |
|
General information |
|
Model name
|
GAS GAS EC 250 Racing |
|
Year
|
2012 |
|
Category
|
Enduro / offroad |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
249.3 ccm (15.21 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Bore x stroke
|
66.4 x 72.0 mm (2.6 x 2.8 inches) |
|
Fuel system
|
Carburettor. Keihin 38 mm - Intake by reed valve |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Fuel mixed 1:50 |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Hydraulic, multidisc in oil bath |
|
Exhaust system
|
FMF |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Chrome molybdenum perimetral frame |
|
Front suspension
|
Inverted MARZOCCHI Ø48 with closed cartridge |
|
Front wheel travel
|
315 mm (12.4 inches) |
|
Rear suspension
|
ÖHLINS hydraulic mono shock absorber |
|
Rear wheel travel
|
320 mm (12.6 inches) |
|
Front tire
|
90/90-21 |
|
Rear tire
|
140/80-18 |
|
Front brakes
|
Double disc. Wave disc, 2-piston caliper |
|
Diameter
|
260 mm (10.2 inches) |
|
Rear brakes
|
Single disc. Wave disc, 1-piston caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Light aluminium spoke rim |
|
Physical measures and capacities |
|
Dry weight
|
102.0 kg (224.9 pounds) |
|
Seat height
|
960 mm (37.8 inches) If adjustable, lowest setting. |
|
Overall height
|
1260 mm (49.6 inches) |
|
Overall length
|
2200 mm (86.6 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Wheelbase
|
1475 mm (58.1 inches) |
|
Fuel capacity
|
10.00 litres (2.64 US gallons) |
|
Other specifications |
|
Color options
|
Black/red/white |
|
Starter
|
Kick |
|
Comments
|
Spanish brand. |
