General information |
|
Model name
|
E-Ton Viper RXL 90 |
|
Year model
|
2012 |
|
Type
|
ATV |
|
Rating
|
3.3 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
88.4 ccm (5.39 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Top speed
|
48.0 km/h (29.8 mph) |
|
Compression
|
10.6:1 |
|
Bore x stroke
|
47.0 x 51.0 mm (1.9 x 2.0 inches) |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
C.D.I. |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Driveline
|
CVT |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
A-Arm, Adjustable shocks |
|
Front wheel travel
|
30 mm (1.2 inches) |
|
Rear suspension
|
Swing Arm and Adjustable shocks |
|
Rear wheel travel
|
40 mm (1.6 inches) |
|
Front tire
|
18/7-8 |
|
Rear tire
|
18/9-8 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
85 mm (3.3 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
190 mm (7.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
113.0 kg (249.1 pounds) |
|
Seat height
|
680 mm (26.8 inches) If adjustable, lowest setting. |
|
Overall height
|
900 mm (35.4 inches) |
|
Overall length
|
1500 mm (59.1 inches) |
|
Overall width
|
850 mm (33.5 inches) |
|
Ground clearance
|
120 mm (4.7 inches) |
|
Wheelbase
|
930 mm (36.6 inches) |
|
Fuel capacity
|
3.60 litres (0.95 US gallons) |
|
Other specifications |
|
Color options
|
Blue, Pink, Black/Silver |
|
Starter
|
Electric & kick |
|
Electrical
|
4Ah / 12V battery |
|
Comments
|
Made in Taiwan |
