General information |
|
Motorcycle name
|
E-Ton Viper 90 R |
|
Year
|
2010 |
|
Category
|
ATV |
|
Rating
|
3.6 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
88.4 ccm (5.39 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Top speed
|
48.0 km/h (29.8 mph) |
|
Compression
|
10.6:1 |
|
Bore x stroke
|
57.4 x 57.8 mm (2.3 x 2.3 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
C.D.I. |
|
Cooling system
|
Oil & air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
A-Arm |
|
Front wheel travel
|
50 mm (2.0 inches) |
|
Rear suspension
|
Swing arm |
|
Rear wheel travel
|
75 mm (3.0 inches) |
|
Front tire
|
21/6-10 |
|
Rear tire
|
20/10-9 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
85 mm (3.3 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
190 mm (7.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
113.0 kg (249.1 pounds) |
|
Seat height
|
680 mm (26.8 inches) If adjustable, lowest setting. |
|
Overall height
|
900 mm (35.4 inches) |
|
Overall length
|
1500 mm (59.1 inches) |
|
Overall width
|
850 mm (33.5 inches) |
|
Ground clearance
|
120 mm (4.7 inches) |
|
Wheelbase
|
930 mm (36.6 inches) |
|
Fuel capacity
|
3.60 litres (0.95 US gallons) |
|
Other specifications |
|
Color options
|
Blue, Pink, Black/Silver |
|
Starter
|
Electric & kick |
|
Comments
|
Off-road ATV. |
