| E-Ton's profilation of this bike |
| With a sleek outlook, the E-TON VECTOR ST.300 is made for winners who are always looking for excellence and uniqueness. |
| General information |
|---|
| Model: | E-Ton Vector ST 300 |
| Year: | 2012 |
| Category: | ATV |
| Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 287.20 ccm (17.52 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 10.0:1 |
| Bore x stroke: | 75.0 x 0.0 mm (3.0 x inches) |
| Fuel system: | Carburettor |
| Ignition: | C.D.I. |
| Cooling system: | Liquid |
Transmission type,
final drive: | Belt |
| Driveline: | CVT |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Double A-Arm and Adjustable shocks |
| Front wheel travel: | 75 mm (3.0 inches) |
| Rear suspension: | Swing Arm and Adjustable shocks |
| Rear wheel travel: | 100 mm (3.9 inches) |
| Front tyre: | 21/7-10 |
| Rear tyre: | 22/10-10 |
| Front brakes: | Double disc. Hydraulic |
| Front brakes diameter: | 175 mm (6.9 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 220 mm (8.7 inches) |
| Wheels: | BATTERY |
| Physical measures and capacities |
|---|
| Dry weight: | 225.0 kg (496.0 pounds) |
| Seat height: | 890 mm (35.0 inches) If adjustable, lowest setting. |
| Overall height: | 1,130 mm (44.5 inches) |
| Overall length: | 1,815 mm (71.5 inches) |
| Overall width: | 1,062 mm (41.8 inches) |
| Ground clearance: | 150 mm (5.9 inches) |
| Wheelbase: | 1,193 mm (47.0 inches) |
| Fuel capacity: | 12.00 litres (3.17 gallons) |
| Other specifications |
|---|
| Color options: | Silver, Black, Orange |
| Starter: | Electric |
