General information |
Model name
|
Ducati Monster 1100 EVO 20th Anniversary |
Year model
|
2013 |
Type
|
Naked bike |
Rating
|
3.7 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
Engine and transmission |
Engine size
|
1078.0 ccm (65.78 cubic inches) |
Type of engine
|
V2, four-stroke |
Effect
|
98.6 HP (71.9 kW)) @ 7500 RPM |
Torque
|
103.0 Nm (10.5 kgf-m or 76.0 ft.lbs) @ 6000 RPM |
Compression
|
11.3:1 |
Bore x stroke
|
98.0 x 71.5 mm (3.9 x 2.8 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Injection. Siemens electronic fuel injection, 45mm throttle body |
Fuel control
|
Desmodromic valve control |
Cooling system
|
Air |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Emission details
|
Euro 3 |
Exhaust system
|
Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers |
Chassis, suspension, brakes and wheels |
Frame type
|
Tubular steel Trellis frame |
Rake (fork angle)
|
24.0° |
Trail
|
87 mm (3.4 inches) |
Front suspension
|
Marzocchi 43mm fully adjustable usd forks |
Rear suspension
|
Progressive with preload and rebound Sachs adjustable monoshock |
Front tire
|
120/70-ZR17 |
Rear tire
|
180/55-ZR17 |
Front brakes
|
Double disc. ABS. Four-piston calipers. Gold finished Brembo braking system. |
Diameter
|
320 mm (12.6 inches) |
Rear brakes
|
Single disc. ABS. Two-piston calipers. Gold finished Brembo braking system. |
Diameter
|
245 mm (9.6 inches) |
Physical measures and capacities |
Dry weight
|
169.0 kg (372.6 pounds) |
Power/weight ratio
|
0.5833 HP/kg |
Seat height
|
810 mm (31.9 inches) If adjustable, lowest setting. |
Wheelbase
|
1450 mm (57.1 inches) |
Fuel capacity
|
13.50 litres (3.57 US gallons) |
Other specifications |
Color options
|
Red/black/bronze |
Light
|
Chrome plated headlamp support. |
Factory warranty
|
24 months unlimited mileage |
