| Derbi's profilation of this bike |
| Mature in its content and concept, it has been designed to manage the traps of the city and the obstacles of Off Road terrains. |
| General information |
|---|
| Model: | Derbi Terra 125 |
| Year: | 2011 |
| Category: | Allround |
| Price as new: | Euro 3763. UK £ 2974. MSRP depends on country, taxes, accessories, etc. |
| Rating: | 3.4 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
| Engine and transmission |
|---|
| Displacement: | 124.2 ccm (7.58 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 15.0 HP (10.9 kW)) @ 9250 RPM |
| Compression: | 12.0:1 |
| Bore x stroke: | 58.0 x 47.0 mm (2.3 x 1.9 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor. 30 mm |
| Fuel control: | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition: | CDI |
| Lubrication system: | Dry sump with integrated oil deposit |
| Cooling system: | Liquid |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Multi-plate in oil bath |
| Emission details: | Euro 3 |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel double-beamed frame. Double steel swing arm. |
| Front suspension: | Hydraulic fork |
| Front wheel travel: | 150 mm (5.9 inches) |
| Rear suspension: | Mono-shock with adjustable spring pre-load. |
| Front tire: | 100/90-18 |
| Rear tire: | 130/80-17 |
| Front brakes: | Single disc |
| Diameter: | 280 mm (11.0 inches) |
| Rear brakes: | Single disc |
| Diameter: | 220 mm (8.7 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 117.0 kg (257.9 pounds) |
| Power/weight ratio: | 0.1282 HP/kg |
| Seat height: | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Overall height: | 1260 mm (49.6 inches) |
| Overall length: | 2144 mm (84.4 inches) |
| Overall width: | 815 mm (32.1 inches) |
| Wheelbase: | 1440 mm (56.7 inches) |
| Fuel capacity: | 12.00 litres (3.17 US gallons) |
| Other specifications |
|---|
| Color options: | Black, red |
| Starter: | Electric |
| Comments: | Spanish bike. |
| Update specs | Report missing specs or required updates. |
| Further information |
|---|
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Finance options | Compare US motorcycle loan quotes from the nation's top providers. |
| Parts finder | Revzilla offers up to 50% off motorcycle accessories. Ships to most countries.
Also check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 11 Derbi Terra 125 discussion group or the general Derbi discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Derbi bike
|
Offroad capabilities for the 2011 Derbi Terra 125:
 (74.0 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
