Derbi Sonar 50 2T 20122012 Derbi Sonar 50 2T specifications, pictures, reviews and rating |
2012 Derbi Sonar 50 2T. Image credits - Derbi.
| Derbi's profilation of this bike |
| The elegance of the Sonar lines takes on a sporty touch with the graphics emphasising the youthful character that´s typically Derbi. Great style and forceful sportiness are also implied by the black colour of the big rims, perfectly matched with the classic, sober colours of the new Sonar´s bodywork. |
| General moped information | |
|---|---|
| Model | Derbi Sonar 50 2T |
| Year | 2012 |
| Category | Scooter |
| Price as new | Euro 1850. MSRP depends on country, taxes, accessories, etc. |
| Rating | 3.7 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 49.4 ccm (3.01 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Power | 4.6 HP (3.4 kW)) @ 7250 RPM |
| Torque | 4.7 Nm (0.5 kgf-m or 3.5 ft.lbs) @ 6750 RPM |
| Compression | 10.9:1 |
| Bore x stroke | 40.0 x 39.3 mm (1.6 x 1.5 inches) |
| Fuel system | Carburettor |
| Lubrication system | Mechanical oil pump |
| Cooling system | Air |
| Gearbox | Automatic |
| Transmission type | Belt (final drive) |
| Clutch | Automatic centrifugal |
| Driveline | Automatic CVT |
| Chassis, suspension, brakes and wheels | |
| Front suspension | Hydraulic fork. |
| Front wheel travel | 76 mm (3.0 inches) |
| Rear suspension | Single shock absorber |
| Rear wheel travel | 64 mm (2.5 inches) |
| Front tire | 90/80-16 |
| Rear tire | 110/80-14 |
| Front brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 140 mm (5.5 inches) |
| Wheels | 5-spoke black wheels |
| Physical measures and capacities | |
| Dry weight | 95.0 kg (209.4 pounds) |
| Weight incl. oil, gas, etc | 103.0 kg (227.1 pounds) |
| Power/weight ratio | 0.0484 HP/kg |
| Seat height | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Overall length | 1960 mm (77.2 inches) |
| Overall width | 735 mm (28.9 inches) |
| Wheelbase | 1340 mm (52.8 inches) |
| Fuel capacity | 6.00 litres (1.59 US gallons) |
| Other specifications | |
| Color options | Black, white |
| Starter | Electric & kick |
| Carrying capacity | Compartment underthe seat to hold a jet helmet. |
| Comments | Spanish bike. |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 12 Derbi Sonar 50 2T discussion group or the general Derbi discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Free motorcycle classifieds
Click here to sell a used 2012 Derbi Sonar 50 2T or advertise any other MC for sale. You can list all available Derbi Sonar 50 2T bikes and also sign up for e-mail notification when such motorcycles are advertised in the future. Ads with or without pictures are easy to create. Our classifieds are completely free with sections for every country in the world. You can also check out our list of related motorbikes. Compare technical data. Look at photos. View your fellow riders' rating of the bike's reliability, design, engine performance, accident risk, repair cost, etc.| Rating sample for this Derbi moped | |
Reliability for the 2012 Derbi Sonar 50 2T:  (72.4 out of 100)Click here for complete rating. |
|
