| Derbi's profilation of this bike |
| Aluminium perimeter double beamed frame with support and protection cradle for the engine. Upside down 41 mm diameter fork, aluminium progressive link swingarm. Front brakes with pump and radial caliper.
|
|
General moped information |
|
Model name
|
Derbi Senda DRD Pro 50 R |
|
Year
|
2010 |
|
Category
|
Enduro / offroad |
|
Rating
|
2.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
49.9 ccm (3.04 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
39.9 x 40.0 mm (1.6 x 1.6 inches) |
|
Fuel system
|
Carburettor. 17.5 mm |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Mechanical oil pump |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multidisc |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
40 mm Upside down fork. |
|
Front wheel travel
|
250 mm (9.8 inches) |
|
Rear suspension
|
Progressive linkage monoshock with separate gas tank. |
|
Rear wheel travel
|
250 mm (9.8 inches) |
|
Front tire
|
90/90-21 |
|
Rear tire
|
110/80-18 |
|
Front brakes
|
Single disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
96.0 kg (211.6 pounds) |
|
Weight incl. oil, gas, etc
|
104.0 kg (229.3 pounds) |
|
Seat height
|
920 mm (36.2 inches) If adjustable, lowest setting. |
|
Overall height
|
1196 mm (47.1 inches) |
|
Overall length
|
2080 mm (81.9 inches) |
|
Overall width
|
808 mm (31.8 inches) |
|
Wheelbase
|
1390 mm (54.7 inches) |
|
Fuel capacity
|
6.50 litres (1.72 US gallons) |
|
Reserve fuel capacity
|
1.30 litres (0.34 US gallons) |
|
Other specifications |
|
Color options
|
Red/black/gray |
|
Starter
|
Electric |
|
Comments
|
Derbi is a Spanish brand. |
