| Derbi's profilation of this bike |
| The new DRD EVO 50 LIMITED EDITION is the last evolution of the existing DRD EVO 50 SM.
Only available in a limited distribution.
|
|
General moped information |
|
Motorcycle name
|
Derbi Senda DRD Evo 50 SM Limited |
|
Year
|
2009 |
|
Category
|
Super motard |
|
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
49.9 ccm (3.04 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
39.9 x 40.0 mm (1.6 x 1.6 inches) |
|
Fuel system
|
Carburettor. 17.5 mm |
|
Ignition
|
Electronic CDI |
|
Lubrication system
|
Mechanical oil pump |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multi-plate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel perimetral double beam |
|
Front suspension
|
40 mm. Upside down fork. |
|
Front wheel travel
|
150 mm (5.9 inches) |
|
Rear suspension
|
Progressive linkage monoshock with separate gas tank. |
|
Rear wheel travel
|
150 mm (5.9 inches) |
|
Front tire
|
100/80-17 |
|
Rear tire
|
130/70-17 |
|
Front brakes
|
Single disc. Wavw |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc. Wave |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
99.0 kg (218.3 pounds) |
|
Seat height
|
838 mm (33.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1130 mm (44.5 inches) |
|
Overall length
|
2014 mm (79.3 inches) |
|
Overall width
|
838 mm (33.0 inches) |
|
Wheelbase
|
1374 mm (54.1 inches) |
|
Fuel capacity
|
7.00 litres (1.85 US gallons) |
|
Other specifications |
|
Color options
|
Black |
|
Starter
|
Electric |
