| Derbi's profilation of this bike |
| It features a single cylinder, liquid-cooled, 2-stroke engine, the double-beamed aluminium chassis, a sporty exhaust with an inverted exhaust pipe and a complete set of analogue instruments. |
|
General moped information |
|
Model
|
Derbi GP1 50 |
|
Model year
|
2012 |
|
Category
|
Scooter |
|
Rating
|
3.2 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
49.4 ccm (3.01 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Compression
|
10.5:1 |
|
Bore x stroke
|
40.0 x 39.3 mm (1.6 x 1.5 inches) |
|
Fuel system
|
Carburettor. 17.5 mm |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Electronic C.D.I. |
|
Lubrication system
|
Separate mixing with mechanical oil pump |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Automated twist and go |
|
Driveline
|
Automatic CVT |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminium beam frame |
|
Front suspension
|
Inverted fork |
|
Front wheel travel
|
80 mm (3.1 inches) |
|
Rear suspension
|
Aluminium swingarm with single spring-damper |
|
Rear wheel travel
|
70 mm (2.8 inches) |
|
Front tire
|
120/70-14 |
|
Rear tire
|
140/60-13 |
|
Front brakes
|
Single disc. Radially-mounted two-piston caliper |
|
Diameter
|
190 mm (7.5 inches) |
|
Rear brakes
|
Single disc. Single piston |
|
Diameter
|
175 mm (6.9 inches) |
|
Seat
|
Dual seat |
|
Physical measures and capacities |
|
Dry weight
|
103.0 kg (227.1 pounds) |
|
Weight incl. oil, gas, etc
|
115.0 kg (253.5 pounds) |
|
Seat height
|
835 mm (32.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1175 mm (46.3 inches) |
|
Overall length
|
1850 mm (72.8 inches) |
|
Wheelbase
|
1330 mm (52.4 inches) |
|
Fuel capacity
|
11.00 litres (2.91 US gallons) |
|
Oil capacity
|
1.50 litres (1.59 US quarts) |
|
Other specifications |
|
Color options
|
Black |
|
Starter
|
Electric |
|
Instruments
|
Analogue |
|
Light
|
Dual head lights |
|
Comments
|
Spanish made scooter. |
