| Derbi's profilation of this bike |
| The new Derbi DH 2.0 is pure passion, a machine taken to the minimum to achieve the maximum. |
|
General information |
|
Model name
|
Derbi DH 2.0 |
|
Year of manufacture
|
2009 |
|
Type
|
Prototype / concept model |
|
Rating
|
3.5 See the detailed rating of design and look, fun-factor, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
96.2 ccm (5.87 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
10.7 HP (7.8 kW)) @ 8500 RPM |
|
Torque
|
7.1 Nm (0.7 kgf-m or 5.2 ft.lbs) @ 6000 RPM |
|
Compression
|
11.0:1 |
|
Bore x stroke
|
50.0 x 49.0 mm (2.0 x 1.9 inches) |
|
Lubrication system
|
Dry sump |
|
Cooling system
|
Air |
|
Gearbox
|
1-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet automatic centrifugal |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminium. Integrated fuel tank |
|
Front suspension
|
38 upside down fork. 200 mm travel |
|
Rear suspension
|
Air monoshock, and flexible carbon cantilever. Wheel travel 150 mm |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
40.0 kg (88.1 pounds) |
|
Power/weight ratio
|
0.2683 HP/kg |
|
Overall width
|
710 mm (28.0 inches) |
|
Wheelbase
|
1296 mm (51.0 inches) |
|
Fuel capacity
|
2.00 litres (0.53 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
