DB Motors ZZ 2010


2010 DB Motors ZZ specifications, pictures, reviews and rating

2010 DB Motors ZZ
Picture credits - DB Motors. Click to submit more pictures.

   Show big 2010 DB Motors ZZ picture
2010 DB Motors ZZ
Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale
List all mopeds
Tip a friend
List related bikes


General moped information
Model:DB Motors ZZ
Year:2010
Category:Minibike, cross
Rating:Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating.
Engine and transmission
Displacement:49.80 ccm (3.04 cubic inches)
Engine type:Single cylinder, four-stroke
Power:2.50 HP (1.8 kW)) @ 7500 RPM
Compression:9.5:1
Bore x stroke:39.0 x 41.7 mm (1.5 x 1.6 inches)
Fuel system:Carburettor. Dellorto SHA 14/12
Ignition:Electronic
Lubrication system:2% mixture
Gearbox:Automatic
Transmission type,
final drive:
Chain
Clutch:Automatic centrifugal light 2-shoe oil
Exhaust system:Racing-type with aluminium muffler
Chassis, suspension, brakes and wheels
Frame type:Single steel beam frame
Front suspension:Magnum 32mm hydraulic telescopic fork
Rear suspension:Mechanical shock absorber
Front tyre:2.50-10
Rear tyre:2.50-10
Front brakes:Expanding brake (drum brake). Drum brake with extractable pin
Front brakes diameter:90 mm (3.5 inches)
Rear brakes:Expanding brake (drum brake). Drum brake with extractable pin
Rear brakes diameter:90 mm (3.5 inches)
Physical measures and capacities
Dry weight:42.0 kg (92.6 pounds)
Power/weight ratio:0.0595 HP/kg
Seat height:640 mm (25.2 inches) If adjustable, lowest setting.
Overall height:930 mm (36.6 inches)
Overall length:1,370 mm (53.9 inches)
Overall width:300 mm (11.8 inches)
Wheelbase:957 mm (37.7 inches)
Fuel capacity:4.20 litres (1.11 gallons)
Other specifications
Color options:Multicolored
Starter:Kick
Comments:Available with 10´-10´ or 12´-14´ wheels. Italian brand.
