General moped information |
|
Model name
|
DB Motors ZZ 10-10 inch wheels |
|
Year model
|
2007 |
|
Type
|
Minibike, cross |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
49.8 ccm (3.04 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Effect
|
2.5 HP (1.8 kW)) @ 7500 RPM |
|
Compression
|
9.5:1 |
|
Bore x stroke
|
39.0 x 41.7 mm (1.5 x 1.6 inches) |
|
Fuel system
|
Carburettor. Dellorto SHA 14/12 |
|
Ignition
|
Electronic |
|
Gearbox
|
Automatic |
|
Clutch
|
Automatic centrifugal light 2-shoe oil |
|
Exhaust system
|
racing-type with aluminium muffler |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Single steel beam frame |
|
Front suspension
|
Magnum 32mm hydraulic telescopic fork |
|
Rear suspension
|
Mechanical shock absorber |
|
Front tire
|
2.50-10 |
|
Rear tire
|
2.50-10 |
|
Front brakes
|
Expanding brake (drum brake). 90 mm drum brake with extractable pin |
|
Diameter
|
90 mm (3.5 inches) |
|
Rear brakes
|
Expanding brake (drum brake). 90 mm drum brake with extractable pin |
|
Diameter
|
90 mm (3.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
42.0 kg (92.6 pounds) |
|
Power/weight ratio
|
0.0595 HP/kg |
|
Seat height
|
640 mm (25.2 inches) If adjustable, lowest setting. |
|
Overall height
|
930 mm (36.6 inches) |
|
Overall length
|
1370 mm (53.9 inches) |
|
Overall width
|
300 mm (11.8 inches) |
|
Wheelbase
|
957 mm (37.7 inches) |
|
Fuel capacity
|
4.20 litres (1.11 US gallons) |
|
