DB Motors Super Sport 20092009 DB Motors Super Sport specifications, pictures, reviews and rating |
![]() 2009 DB Motors Super Sport. Picture credits - DB Motors. Submit more pictures.
|
General moped information | |
---|---|
Model: | DB Motors Super Sport |
Year: | 2009 |
Category: | Minibike, cross |
Rating: | Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
Engine and transmission | |
Displacement: | 49.8 ccm (3.04 cubic inches) |
Engine type: | Single cylinder, two-stroke |
Power: | 2.5 HP (1.8 kW)) @ 7500 RPM |
Compression: | 9.5:1 |
Bore x stroke: | 39.0 x 41.7 mm (1.5 x 1.6 inches) |
Fuel system: | Carburettor. Dell’Orto |
Ignition: | Electronic |
Lubrication system: | Oil and premium grade gasoline - mixture at 2% |
Gearbox: | Automatic |
Transmission type, final drive: | Chain |
Clutch: | Automatic centrifugal light 2-shoe oil batch clutch. |
Exhaust system: | Racing-type with aluminium muffler |
Chassis, suspension, brakes and wheels | |
Frame type: | Single steel beam frame |
Front suspension: | Magnum 32mm hydraulic telescopic fork |
Rear suspension: | Mechanical shock absorber |
Front brakes: | Expanding brake (drum brake). Drum brake with extractable pin |
Rear brakes: | Expanding brake (drum brake). Drum brake with extractable pin |
Physical measures and capacities | |
Dry weight: | 43.5 kg (95.9 pounds) |
Power/weight ratio: | 0.0575 HP/kg |
Seat height: | 660 mm (26.0 inches) If adjustable, lowest setting. |
Overall height: | 930 mm (36.6 inches) |
Overall length: | 1400 mm (55.1 inches) |
Wheelbase: | 957 mm (37.7 inches) |
Fuel capacity: | 4.20 litres (1.11 gallons) |
Other specifications | |
Starter: | Kick |
Comments: | Two wheel options: 10´-10´ or 12´-14´ |
