| Dam's profilation of this bike |
| Highly Engineered DAM APEX chassis: Oil in frame with over 5-quart capacity, 3-D steering head bracing, Super bike inspired single sided swing arm. |
| General information |
|---|
| Model | Dam Tech Twin American 13c Pennsylvania |
| Year | 2011 |
| Category | Custom / cruiser |
| Rating | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement | 2081.3 ccm (127.00 cubic inches) |
| Engine type | V2, four-stroke |
| Engine details | R and R |
| Power | 140.0 HP (102.2 kW)) |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Gearbox | 6-speed |
| Transmission type | Belt (final drive) |
| Driveline | Baker RSD 6-speed |
| Exhaust system | Hand made stainless steel with an under chassis NASCARR styled muffler |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | DAM Motorcycles/Apex |
| Rake (fork angle) | 35.0° |
| Front suspension | Penske Racing |
| Rear suspension | DAM/Single Sided swingarm |
| Front tire | 80/90-21 |
| Rear tire | 240/40-18 |
| Front brakes | Single disc. Radial mount 4 piston Brembo Calipers |
| Rear brakes | Single disc. Radial mount 4 piston Brembo Caliper |
| Wheels | BST Carbon Fiber/21 x 2.15 front, BST Carbon Fiber/18 x 8.5 rear |
| Physical measures and capacities |
|---|
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Other specifications |
|---|
| Comments | R and R engine. Carbon fiber wheels. Limited edition model. |
