General information |
|
Motorcycle name
|
CZ 175 Trail |
|
Year
|
1976 |
|
Category
|
Scooter |
|
Rating
|
2.5 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
172.0 ccm (10.50 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power
|
15.0 HP (10.9 kW)) @ 5600 RPM |
|
Top speed
|
100.0 km/h (62.1 mph) |
|
Compression
|
8.7:1 |
|
Bore x stroke
|
58.0 x 65.0 mm (2.3 x 2.6 inches) |
|
Fuel control
|
Port control |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
2.75-21 |
|
Rear tire
|
3.50-18 |
|
Front brakes
|
Expanding brake |
|
Rear brakes
|
Expanding brake |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
128.0 kg (282.2 pounds) |
|
Fuel capacity
|
11.00 litres (2.91 US gallons) |
|
Other specifications |
