General information |
|
Model
|
CZ 125 Sport |
|
Model year
|
1974 |
|
Category
|
Touring |
|
Rating
|
2.7 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
|
Engine and transmission |
|
Displacement
|
123.2 ccm (7.52 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power output
|
11.0 HP (8.0 kW)) |
|
Top speed
|
99.8 km/h (62.0 mph) |
|
Max RPM
|
5750 |
|
Compression
|
8.8:1 |
|
Bore x stroke
|
52.0 x 58.0 mm (2.0 x 2.3 inches) |
|
Fuel system
|
Carburettor. Jikov 24mm |
|
Lubrication system
|
Fuel mix |
|
Cooling system
|
Air |
|
Gearbox
|
4-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet plate |
|
Exhaust system
|
Single pipe |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular |
|
Front suspension
|
Forks |
|
Front wheel travel
|
130 mm (5.1 inches) |
|
Rear suspension
|
Twin shocks |
|
Rear wheel travel
|
100 mm (3.9 inches) |
|
Front tire
|
3.00-18 |
|
Rear tire
|
3.00-18 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
160 mm (6.3 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
160 mm (6.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
112.0 kg (246.9 pounds) |
|
Power/weight ratio
|
0.0982 HP/kg |
|
Overall height
|
1005 mm (39.6 inches) |
|
Overall length
|
1295 mm (51.0 inches) |
|
Overall width
|
650 mm (25.6 inches) |
|
Ground clearance
|
84 mm (3.3 inches) |
|
Wheelbase
|
1950 mm (76.8 inches) |
|
Fuel capacity
|
11.50 litres (3.04 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
