General information |
|
Model name
|
CR&S VUN PPB Sidecar |
|
Year
|
2012 |
|
Category
|
Naked bike |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
652.0 ccm (39.79 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Engine details
|
Bombardier-Rotax / CR and S type 654 |
|
Power
|
28.2 HP (20.6 kW)) |
|
Torque
|
37.0 Nm (3.8 kgf-m or 27.3 ft.lbs) |
|
Compression
|
9.7:1 |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. IIntegrated CR and S/Walbro/Dell’Orto ignition/injection system, 52 mm throttle housing, twin injectors, twin spark |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Lubrication system
|
Dry sump |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multiple disc wet |
|
Exhaust system
|
Stainless steel catalytic exhaust system (CR and S by QD) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel tubes and machined light alloy plates compound |
|
Front suspension
|
Tele-hydraulic fork with 46mm diameter rods |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Oscillating swingarm, single shock absorber |
|
Rear wheel travel
|
128 mm (5.0 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
160/60-ZR17 |
|
Front brakes
|
Single disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Cast alumnium. 15 inch sidecar wheel. |
|
Seat
|
Neoprene seat |
|
Physical measures and capacities |
|
Seat height
|
780 mm (30.7 inches) If adjustable, lowest setting. |
|
Alternate seat height
|
820 mm (32.3 inches) If adjustable, highest setting. |
|
Overall length
|
1980 mm (78.0 inches) |
|
Ground clearance
|
150 mm (5.9 inches) |
|
Wheelbase
|
1368 mm (53.9 inches) |
|
Fuel capacity
|
12.50 litres (3.30 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
|
Comments
|
The CR and S VUN PPB is a sidecar to be fitted to a VUN Road Motorcyle. The VUN SIDECAR cannot carry any passenger, just goods. It’s not homologated by itself, when fastened together a CR and S VUN road motorcycle, must be legalized as new vehicle. |
