| Cobra's profilation of this bike |
| With the many new upgrades 2009 looks to be another banner year for Cobra quadracers!
|
|
General moped information |
|
Model name
|
Cobra ECX50 |
|
Year
|
2009 |
|
Category
|
ATV |
| Price as new | US$ 6998. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
50.0 ccm (3.05 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Bore x stroke
|
39.0 x 41.7 mm (1.5 x 1.6 inches) |
|
Lubrication system
|
Mixture lubrication |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Cobra 3Gx 3-Shoe |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Arens design twin spar |
|
Front suspension
|
Dual A-Arm with SVO and trade |
|
Rear suspension
|
Öhlins Piggyback |
|
Front brakes
|
Single disc |
|
Diameter
|
160 mm (6.3 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
180 mm (7.1 inches) |
|
Physical measures and capacities |
|
Dry weight
|
93.4 kg (206.0 pounds) |
|
Seat height
|
737 mm (29.0 inches) If adjustable, lowest setting. |
|
Ground clearance
|
205 mm (8.1 inches) |
|
Wheelbase
|
1067 mm (42.0 inches) |
|
Other specifications |
