| CH Racing's profilation of this bike |
| We produce only 20 pieces per year; this bike has dominated 50cc Italian Championship the last two years. There are no other competitors at same level. A real jewel for only 20 lucky guys! |
|
General moped information |
|
Model
|
CH Racing WXE 50 Racing |
|
Year model
|
2008 |
|
Type
|
Enduro / offroad |
|
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.7 ccm (3.03 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Fuel system
|
Carburettor. PHBN 16 |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Up-side down telescopic hydraulic fork dia 40mm |
|
Rear suspension
|
Progressiv unitrac type with single shock absorber |
|
Front tire
|
80/90-21 |
|
Rear tire
|
110/80-18 |
|
Front brakes
|
Single disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
185 mm (7.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
92.0 kg (202.8 pounds) |
|
Overall height
|
1200 mm (47.2 inches) |
|
Overall length
|
1990 mm (78.3 inches) |
|
Overall width
|
810 mm (31.9 inches) |
|
Ground clearance
|
340 mm (13.4 inches) |
|
Wheelbase
|
1375 mm (54.1 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Other specifications |
|
Starter
|
Kick |
