| Cectek's profilation of this bike |
| We have built the most innovative ATVs for your enjoyment of riding. Our next generation ATVs have been equipped with not only rugged power but also user friendly operation, highly secure handling performance and graceful styling. |
|
General information |
|
Model name
|
Cectek Kingcobra 500 EFI |
|
Year
|
2011 |
|
Category
|
ATV |
|
Rating
|
2.3 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
497.0 ccm (30.33 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power
|
40.2 HP (29.4 kW)) @ 6500 RPM |
|
Torque
|
44.0 Nm (4.5 kgf-m or 32.5 ft.lbs) @ 4500 RPM |
|
Compression
|
10.1:1 |
|
Bore x stroke
|
90.0 x 78.0 mm (3.5 x 3.1 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Close loop electronics fuel injection (EFI) |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Liquid |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Non-centrifugal clutch CVT system with engine braking function |
|
Driveline
|
Park, Reverse, Neuter, High, Low, and 2/4WD gears inside the crankcase |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Independent, double A-arm, forged aluminium upper arm |
|
Front wheel travel
|
134 mm (5.3 inches) |
|
Rear suspension
|
Independent, double A-arm, forged aluminium upper arm |
|
Rear wheel travel
|
144 mm (5.7 inches) |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Double disc. Hydraulic |
|
Diameter
|
200 mm (7.9 inches) |
|
Rear brakes
|
Double disc. Hydraulic |
|
Diameter
|
200 mm (7.9 inches) |
|
Wheels
|
Cast aluminum rim with low profile highway tires |
|
Seat
|
2-passenger seat |
|
Physical measures and capacities |
|
Seat height
|
916 mm (36.1 inches) If adjustable, lowest setting. |
|
Overall height
|
1251 mm (49.3 inches) |
|
Overall length
|
2016 mm (79.4 inches) |
|
Overall width
|
1241 mm (48.9 inches) |
|
Ground clearance
|
300 mm (11.8 inches) |
|
Wheelbase
|
1330 mm (52.4 inches) |
|
Fuel capacity
|
19.00 litres (5.02 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
|
Light
|
4 head lights |
|
Carrying capacity
|
150 kg towing capacity |
