CCM C-XR230-E 20102010 CCM C-XR230-E specifications, pictures, reviews and rating |
| CCM's profilation of this bike |
| The C-XR230 is excellent value for money, offering an enduro, supermoto and entry level MX machine in one punchy package. |
| General information | |
|---|---|
| Model | CCM C-XR230-E |
| Year of manufacture | 2010 |
| Type | Enduro / offroad |
| Rating |
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission | |
| Engine size | 230.0 ccm (14.03 cubic inches) |
| Type of engine | Single cylinder, four-stroke |
| Output | 18.0 HP (13.1 kW)) |
| Compression | 9.2:1 |
| Bore x stroke | 67.0 x 65.0 mm (2.6 x 2.6 inches) |
| Fuel system | Carburettor |
| Fuel control | Single Overhead Cams (SOHC) |
| Ignition | C.D.I. |
| Lubrication system | Wet Sump |
| Cooling system | Air |
| Transmission type | Chain (final drive) |
| Chassis, suspension, brakes and wheels | |
| Frame type | Tubular welded steel. Cast / welded aluminium swing arm. |
| Front suspension | Conventional fork, 40mm |
| Rear suspension | Single shock - adjustable preload |
| Front brakes | Single disc |
| Rear brakes | Single disc |
| Physical measures and capacities | |
| Dry weight | 118.0 kg (260.1 pounds) |
| Weight incl. oil, gas, etc | 129.0 kg (284.4 pounds) |
| Power/weight ratio | 0.1525 HP/kg |
| Seat height | 940 mm (37.0 inches) If adjustable, lowest setting. |
| Ground clearance | 340 mm (13.4 inches) |
| Wheelbase | 1350 mm (53.1 inches) |
| Fuel capacity | 8.80 litres (2.32 US gallons) |
| Other specifications | |
| Color options | White/red |
| Starter | Electric |
| Comments | CCM is a British brand. |
