| Can-Am's profilation of this bike |
| Say hello to the Outlander 500 EFI. Powered by the only V-twin in the category, it delivers more power (40.4-hp) and a better power-to-weight ratio (6.3 hp per 100 lbs) than any bike in its class. |
|
General information |
|
Motorcycle name
|
Can-Am Outlander 500 EFI |
|
Year of manufacture
|
2010 |
|
Type
|
ATV |
| Price as new | US$ 7799. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
499.6 ccm (30.49 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Bore x stroke
|
82.0 x 47.0 mm (3.2 x 1.9 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Siemens injectors |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Liquid |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
SST |
|
Front suspension
|
McPherson |
|
Front wheel travel
|
178 mm (7.0 inches) |
|
Rear suspension
|
TTI independent |
|
Rear wheel travel
|
229 mm (9.0 inches) |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Single disc. Hydraulic |
|
Rear brakes
|
Single disc. Hydraulic |
|
Physical measures and capacities |
|
Dry weight
|
292.6 kg (645.0 pounds) |
|
Seat height
|
877 mm (34.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1168 mm (46.0 inches) |
|
Overall length
|
2184 mm (86.0 inches) |
|
Overall width
|
1143 mm (45.0 inches) |
|
Ground clearance
|
279 mm (11.0 inches) |
|
Fuel capacity
|
20.06 litres (5.30 US gallons) |
|
Other specifications |
|
Color options
|
Black, yellow |
|
Starter
|
Electric |
|
Comments
|
CVT, sub-transmission w/high, low, park, neutral and reverse, standard Engine braking. Selectable 2w/4w shaft driven w/Visco-lok† front differential. |
