| General information |
|---|
| Model | Cagiva Raptor 650 i.e. |
| Year | 2006 |
| Category | Naked bike |
| Rating | 3.6 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
| Engine and transmission |
|---|
| Displacement | 644.1 ccm (39.30 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 70.0 HP (51.1 kW)) @ 9000 RPM |
| Torque | 63.5 Nm (6.5 kgf-m or 46.8 ft.lbs) @ 7400 RPM |
| Compression | 11.5:1 |
| Bore x stroke | 81.0 x 62.2 mm (3.2 x 2.5 inches) |
| Valves per cylinder | 2 |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | High strength steel tubular frame |
| Front suspension | Upside down telescopic hydraulic fork |
| Front wheel travel | 120 mm (4.7 inches) |
| Rear suspension | Progressive shock absorber with adjustable spring preload |
| Front brakes | Double disc |
| Diameter | 298 mm (11.7 inches) |
| Rear brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 180.0 kg (396.8 pounds) |
| Power/weight ratio | 0.3889 HP/kg |
| Seat height | 775 mm (30.5 inches) If adjustable, lowest setting. |
| Overall length | 2110 mm (83.1 inches) |
| Ground clearance | 165 mm (6.5 inches) |
| Wheelbase | 1438 mm (56.6 inches) |
| Other specifications |
|---|
| Color options | Steel, Rosso Cagiva, Bat Black, Blue Marine |
| Starter | Electric |
