General information |
|
Motorcycle name
|
Cagiva Raptor 650 |
|
Year of manufacture
|
2002 |
|
Type
|
Naked bike |
|
Rating
|
3.7 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
645.0 ccm (39.36 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Output
|
73.0 HP (53.3 kW)) @ 9000 RPM |
|
Torque
|
64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7400 RPM |
|
Bore x stroke
|
81.0 x 62.6 mm (3.2 x 2.5 inches) |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
120/70-17 |
|
Rear tire
|
160/60-17 |
|
Front brakes
|
Dual disc |
|
Diameter
|
298 mm (11.7 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
176.0 kg (388.0 pounds) |
|
Power/weight ratio
|
0.4148 HP/kg |
|
Seat height
|
775 mm (30.5 inches) If adjustable, lowest setting. |
|
Ground clearance
|
140 mm (5.5 inches) |
|
Wheelbase
|
1440 mm (56.7 inches) |
|
Fuel capacity
|
19.30 litres (5.10 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
