General information |
Model
|
Buell 1125R |
Year of manufacture
|
2010 |
Type
|
Sport |
Price as new | US$ 12499. MSRP depends on country, taxes, accessories, etc. |
Rating
|
3.7 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
Engine and transmission |
Engine size
|
1125.9 ccm (68.70 cubic inches) |
Type of engine
|
V2, four-stroke |
Output
|
146.0 HP (106.6 kW)) @ 9800 RPM |
Torque
|
111.2 Nm (11.3 kgf-m or 82.0 ft.lbs) @ 8000 RPM |
Compression
|
12.3:1 |
Bore x stroke
|
103.0 x 67.5 mm (4.1 x 2.7 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Injection. Dual 61 mm down draft throttle bodies, DDFI III fuel injection |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Cooling system
|
Liquid |
Gearbox
|
6-speed |
Transmission type
|
Belt (final drive) |
Clutch
|
Wet, multi-plate, Hydraulic Vacuum Assist (HVA) slipper – action clutch, hydraulic clutch lever effort |
Exhaust system
|
Tuned, tri-pass resonance chamber with integral helmholtz tuning and mass-centralised mounting |
Chassis, suspension, brakes and wheels |
Frame type
|
Black aluminium frame, fuel in frame |
Rake (fork angle)
|
21.0° |
Trail
|
84 mm (3.3 inches) |
Front suspension
|
47 mm Showa inverted forks with adjustable compression damping, rebound damping and spring preload |
Front wheel travel
|
120 mm (4.7 inches) |
Rear suspension
|
Showa coil-over monoshock with external piggyback reservoir and adjustable compression damping, rebound damping and spring preload |
Rear wheel travel
|
127 mm (5.0 inches) |
Front tire
|
120/70-ZR17 |
Rear tire
|
180/55-ZR17 |
Front brakes
|
Single disc. ZTL2-type brake, 8-piston, 4 pads, fixed caliper, single-sided, inside out, stainless steel, floating rotor |
Diameter
|
375 mm (14.8 inches) |
Rear brakes
|
Single disc. Two-piston, direct mount caliper; stainless steel, fixed rotor |
Diameter
|
240 mm (9.4 inches) |
Physical measures and capacities |
Seat height
|
775 mm (30.5 inches) If adjustable, lowest setting. |
Overall length
|
1996 mm (78.6 inches) |
Overall width
|
716 mm (28.2 inches) |
Ground clearance
|
114 mm (4.5 inches) |
Wheelbase
|
1387 mm (54.6 inches) |
Fuel capacity
|
20.00 litres (5.28 US gallons) |
Oil capacity
|
3.10 litres (3.28 US quarts) |
Other specifications |
Color options
|
Racing Red; Arctic White; Midnight Black; All with tinted windscreen |
Starter
|
Electric |
Comments
|
Instrument cluster with ODIS (Onboard Diagnostic Information System) featuring analog tachometer with integrated shift light, digital speedometer on LED display, odometer, ODIS service code display, 4-digit security system with ignition immobiliser, lap timer (records up to 99 lap times) and splits, ambient air temperature, coolant temperature, average and instantaneous fuel consumption, miles to next service display,
low fuel (plus miles traveled on reserve); high beam, neutral, turn signals; clock |
