| Brammo's profilation of this bike |
| The Empulse R has carbon fiber headlight shroud, front and rear fenders, top panel (this is the panel immediately ahead of the colored panel) and rear light housing. The bike has a fully adjustable (gold) front suspension and fully adjustable adjustable rear-suspension. |
|
General information |
|
Model name
|
Brammo Empulse R |
|
Model year
|
2013 |
|
Category
|
Naked bike |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Engine type
|
Electric |
|
Engine details
|
Sealed Permanent AC Synchronous motor |
|
Power output
|
53.6 HP (39.2 kW)) |
|
Torque
|
63.0 Nm (6.4 kgf-m or 46.5 ft.lbs) |
|
Top speed
|
160.9 km/h (100.0 mph) |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
IET 6 speed gearbox with multi-plate, hydraulic activated wet clutch |
|
Emission details
|
No direct emmisions |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Lightweight extruded and welded aluminum - serves a battery tray (patent pending) |
|
Front suspension
|
Fully Adjustable 43mm Marzocchi Forks |
|
Rear suspension
|
Fully Adjustable Sachs Shock |
|
Front tire
|
120/70-17 |
|
Rear tire
|
180/55-17 |
|
Front brakes
|
Double disc. Floating disk with twin four piston Hydraulic Brembo Brake Calipers, Radial Mount |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc. Brembo single disk with dual piston Hydraulic Brembo Brake Caliper |
|
Wheels
|
Marchesini |
|
Physical measures and capacities |
|
Dry weight
|
190.5 kg (420.0 pounds) |
|
Power/weight ratio
|
0.2816 HP/kg |
|
Seat height
|
810 mm (31.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1067 mm (42.0 inches) |
|
Overall length
|
2057 mm (81.0 inches) |
|
Wheelbase
|
1473 mm (58.0 inches) |
|
Other specifications |
|
Color options
|
Red, black, white |
|
Starter
|
Electric |
|
Instruments
|
LCD display; speed, tach, odometer, gear position, energy consumption, battery status, estimated range and system status |
|
Carrying capacity
|
Optional Brammo hard saddle bags and top trunk. |
|
Factory warranty
|
2 Years (Limited Factory Warranty) 1 year Fender-to-Fender Limited Warranty, 2 year Limited Powertrain Warranty (Batteries and Motor) |
|
Comments
|
Brammo Power™ BPM15/90 Lithium-Ion ( NCM Chemistry), 103.6 Volt. Recharge time approximately 8 hours. Range: 125 km. Under deceleration, energy is returned to the battery system to both extend driving range and provide familiar rider feedback. |
