| Borile's profilation of this bike |
| The frame has been the object of a scrupulous study to optimise strength and easy engine maintenance operations: the two oblique tubes right behind the cylinder disappeared to give space to a big rafter that connects steering rod with the engine/swing arm group. |
|
General information |
|
Motorcycle name
|
Borile B 500 CR Cafe Racer |
|
Year of manufacture
|
2005 |
|
Type
|
Naked bike |
|
Rating
|
3.3 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Engine size
|
487.0 ccm (29.72 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
10.3:1 |
|
Bore x stroke
|
87.0 x 82.0 mm (3.4 x 3.2 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Mikuni TM Ø36 |
|
Fuel control
|
Overhead Cams (OHC) |
|
Ignition
|
Electronic |
|
Lubrication system
|
Pump |
|
Cooling system
|
Air |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multidisc in oil bath |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Light alloy 40 mm tubular cradle |
|
Front suspension
|
Ceriani upside down 41 mm fork |
|
Rear suspension
|
Paioli monoshock. |
|
Front brakes
|
Single disc |
|
Diameter
|
315 mm (12.4 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
117.0 kg (257.9 pounds) |
|
Seat height
|
850 mm (33.5 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1400 mm (55.1 inches) |
|
Fuel capacity
|
8.50 litres (2.25 US gallons) |
|
Other specifications |
|
Color options
|
Silver, black |
|
Starter
|
Kick |
