| Borile's profilation of this bike |
| The frame has been the object of a scrupulous study to optimise strength and easy engine maintenance operations: the two oblique tubes right behind the cylinder disappeared to give space to a big rafter that connects steering rod with the engine/swing arm group. |
|
General information |
|
Model
|
Borile B500 CR |
|
Model year
|
2006 |
|
Category
|
Sport |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
487.0 ccm (29.72 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
10.3:1 |
|
Bore x stroke
|
87.0 x 82.0 mm (3.4 x 3.2 inches) |
|
Fuel system
|
Carburettor. Mikuni TM Ø36 |
|
Ignition
|
Electronic |
|
Lubrication system
|
By pump |
|
Cooling system
|
Air |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multidisc in oil bath |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Ceriani upside down fork |
|
Rear suspension
|
Mono Paioli with no levers |
|
Front tire
|
120/70-17 |
|
Rear tire
|
150/70-17 |
|
Front brakes
|
Single disc |
|
Diameter
|
315 mm (12.4 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
117.0 kg (257.9 pounds) |
|
Overall height
|
850 mm (33.5 inches) |
|
Overall length
|
1990 mm (78.3 inches) |
|
Overall width
|
720 mm (28.3 inches) |
|
Ground clearance
|
200 mm (7.9 inches) |
|
Wheelbase
|
1400 mm (55.1 inches) |
|
Fuel capacity
|
8.50 litres (2.25 US gallons) |
|
Other specifications |
