General information |
|
Model
|
BMW K 1200 LT |
|
Model year
|
2005 |
|
Category
|
Touring |
|
Rating
|
3.7 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
|
Engine and transmission |
|
Displacement
|
1171.0 ccm (71.45 cubic inches) |
|
Engine type
|
In-line four, four-stroke |
|
Power output
|
114.0 HP (83.2 kW)) @ 8000 RPM |
|
Torque
|
120.0 Nm (12.2 kgf-m or 88.5 ft.lbs) @ 5250 RPM |
|
Compression
|
10.8:1 |
|
Bore x stroke
|
70.5 x 75.0 mm (2.8 x 3.0 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Electronic intake pipe injection / BMW engine management, Motronic MA 2.4 with overrun fuel cut-off |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Single-disc dry clutch, hydraulically operated |
|
Fuel consumption
|
4.30 litres/100 km (23.3 km/l or 54.70 mpg) |
|
Greenhouse gases
|
99.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Bridge-type frame, die-cast aluminium, engine decoupled from vibrations through bearings |
|
Rake (fork angle)
|
27.0° |
|
Trail
|
117 mm (4.6 inches) |
|
Front suspension
|
BMW Motorrad Telelever |
|
Front wheel travel
|
35 mm (1.4 inches) |
|
Rear suspension
|
Die-cast aluminium single-sided swing arm with BMW Motorrad Paralever |
|
Rear wheel travel
|
135 mm (5.3 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
160/70-ZR17 |
|
Front brakes
|
Double disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
285 mm (11.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
353.5 kg (779.3 pounds) |
|
Weight incl. oil, gas, etc
|
387.0 kg (853.2 pounds) |
|
Power/weight ratio
|
0.3224 HP/kg |
|
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1395 mm (54.9 inches) |
|
Overall length
|
2502 mm (98.5 inches) |
|
Overall width
|
1080 mm (42.5 inches) |
|
Wheelbase
|
1637 mm (64.4 inches) |
|
Fuel capacity
|
24.00 litres (6.34 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
|
Comments
|
ABS brakes. |
