| Bimota's profilation of this bike |
| The DB8 was presented in two versions: two-seater and SP, where the bike´ sportive nature is enhanced by the Brembo brake system which gives a better performance and a lighter weight thanks to the use of carbon. |
| General information |
|---|
| Model | Bimota DB8 SP |
| Year | 2013 |
| Category | Sport |
| Rating | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement | 1198.0 ccm (73.10 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 170.0 HP (124.1 kW)) @ 9750 RPM |
| Torque | 127.0 Nm (12.9 kgf-m or 93.7 ft.lbs) @ 8000 RPM |
| Top speed | 280.0 km/h (174.0 mph) |
| Compression | 12.7:1 |
| Bore x stroke | 106.0 x 67.9 mm (4.2 x 2.7 inches) |
| Valves per cylinder | 4 |
| Fuel system | Injection. Walbro electronic injection |
| Fuel control | Desmodromic valve control |
| Lubrication system | Wet sump |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Dry, multi-disc |
| Exhaust system | 2 in 1 in 1, Titanium silencer. |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | 39NiCrMo4 tubing and machined aluminium alloy plates |
| Rake (fork angle) | 25.0° |
| Trail | 100 mm (3.9 inches) |
| Front suspension | 43mm preload -fully adjustable and DLC treated upside-down forks |
| Rear suspension | Preload-fully adjustable top and lower speed monoshock |
| Front tire | 120/70-17 |
| Rear tire | 190/55-17 |
| Front brakes | Double disc. Monoblock |
| Diameter | 320 mm (12.6 inches) |
| Rear brakes | Single disc. 2 piston Brembo calipers |
| Diameter | 220 mm (8.7 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 175.0 kg (385.8 pounds) |
| Power/weight ratio | 0.9714 HP/kg |
| Seat height | 800 mm (31.5 inches) If adjustable, lowest setting. |
| Overall height | 1115 mm (43.9 inches) |
| Overall length | 2040 mm (80.3 inches) |
| Overall width | 730 mm (28.7 inches) |
| Ground clearance | 135 mm (5.3 inches) |
| Wheelbase | 1430 mm (56.3 inches) |
| Fuel capacity | 18.00 litres (4.76 US gallons) |
