Bimota's profilation of this bike |
At the heart of the new Bimota DB7 is the Ducati 1098 Testastretta Evoluzione engine. Powerful, and light, it makes the kind of power that excites the heart with each twist of the throttle, yet its linear power delivery allows entering and exiting the turns fast a confidently controlled experience. |
General information |
Motorcycle name
|
Bimota DB7 |
Year
|
2008 |
Category
|
Sport |
Rating
|
3.6 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
1098.0 ccm (67.00 cubic inches) |
Engine type
|
V2, four-stroke |
Power
|
95.0 HP (69.3 kW)) @ 7000 RPM |
Torque
|
103.0 Nm (10.5 kgf-m or 76.0 ft.lbs) @ 5500 RPM |
Max RPM
|
10700 |
Compression
|
12.5:1 |
Bore x stroke
|
104.0 x 64.5 mm (4.1 x 2.5 inches) |
Valves per cylinder
|
2 |
Fuel system
|
Injection. Electronic fule injection, 60 mm throttle body |
Fuel control
|
Desmodromic valve control |
Lubrication system
|
Wet sump |
Cooling system
|
Liquid |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Oil Bath Clutch, multi-disc |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
25.0° |
Front suspension
|
UD Marzocchi Fork Full Adjustable |
Front wheel travel
|
120 mm (4.7 inches) |
Rear suspension
|
Monoshock Extreme Tech Full Adjustable |
Rear wheel travel
|
120 mm (4.7 inches) |
Front tire
|
120/70-ZR17 |
Rear tire
|
180/55-ZR17 |
Front brakes
|
Double disc. Double 320 mm floating discs Brembo, Radial Caliper Brembo 4-Pistons, 4-Pads |
Diameter
|
320 mm (12.6 inches) |
Rear brakes
|
Single disc. Bimoto 2-pistons, 2-pads Brembo callipers |
Diameter
|
230 mm (9.1 inches) |
Physical measures and capacities |
Dry weight
|
170.0 kg (374.8 pounds) |
Power/weight ratio
|
0.5588 HP/kg |
Front percentage of weight
|
51.0 |
Rear percentage of weight
|
49.0 |
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
Overall height
|
1115 mm (43.9 inches) |
Overall length
|
2010 mm (79.1 inches) |
Overall width
|
700 mm (27.6 inches) |
Ground clearance
|
170 mm (6.7 inches) |
Wheelbase
|
1435 mm (56.5 inches) |
Fuel capacity
|
16.00 litres (4.23 US gallons) |
Reserve fuel capacity
|
4.00 litres (1.06 US gallons) |
Other specifications |
Starter
|
Electric |
