| Bimota's profilation of this bike |
| The DB6R includes many new carbon fiber components including air conveyors for the radiator, fairing sides, belt-covers, clutch cover, front mudguard, plate holder and side covers. |
|
General information |
|
Motorcycle name
|
Bimota DB6 R |
|
Year model
|
2011 |
|
Type
|
Sport |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
1079.0 ccm (65.84 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Engine details
|
Ducati 1100 DS. Twin cylinder 90°. |
|
Maximum RPM
|
8500 |
|
Compression
|
10.5:1 |
|
Bore x stroke
|
98.0 x 71.5 mm (3.9 x 2.8 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection. Walbro |
|
Fuel control
|
Desmodromic valve control |
|
Lubrication system
|
Wet Sump |
|
Cooling system
|
Oil & air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Dry clutch Multi-disc with hydraulic actuation system |
|
Driveline
|
Primary Drive ratio: 33/61. Final Drive ratio: 15/39. |
|
Exhaust system
|
2 in 1 in 2, inox steel |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
24.0° |
|
Front suspension
|
50 mm Marzocchi UD fork TiN fully adjustable |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Extreme Tech Monoshock fully adjustable, compression low/high speed |
|
Rear wheel travel
|
120 mm (4.7 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/70-ZR17 |
|
Front brakes
|
Double disc. Bremo |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Bremo |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Al Alloy |
|
Physical measures and capacities |
|
Dry weight
|
170.0 kg (374.8 pounds) |
|
Seat height
|
820 mm (32.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1100 mm (43.3 inches) |
|
Overall length
|
2045 mm (80.5 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Ground clearance
|
175 mm (6.9 inches) |
|
Wheelbase
|
1430 mm (56.3 inches) |
|
Fuel capacity
|
16.00 litres (4.23 US gallons) |
|
Reserve fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Other specifications |
|
Color options
|
Red/white |
|
Starter
|
Electric |
