General information |
|
Model
|
Bimota DB5R 1100 |
|
Model year
|
2012 |
|
Category
|
Sport |
|
Rating
|
3.0 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
1078.0 ccm (65.78 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Engine details
|
Ducati 1100DS engine. L-twin. |
|
Power output
|
98.0 HP (71.5 kW)) @ 7000 RPM |
|
Torque
|
103.0 Nm (10.5 kgf-m or 76.0 ft.lbs) @ 5500 RPM |
|
Max RPM
|
9000 |
|
Compression
|
10.1:1 |
|
Bore x stroke
|
98.0 x 71.5 mm (3.9 x 2.8 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection. Magneti Marelli-45mm throttle body |
|
Fuel control
|
Desmodromic valve control |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Slipper clutch |
|
Exhaust system
|
2 in 1 in 2, inox |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
CrMo steel trellis, carbon fibre. |
|
Rake (fork angle)
|
24.0° |
|
Trail
|
100 mm (3.9 inches) |
|
Front suspension
|
43mm UD Öhlins TIN Coated Fork, fully adjustable (Pre-load, Compression, Rebound) |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Öhlins Monoshock, fully adjustable (Pre-load - External Hydraulic Device, Compression, Rebound) |
|
Rear wheel travel
|
120 mm (4.7 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
180/55-17 |
|
Front brakes
|
Single disc. Brembo, 4-pistons, 4-pads with radial Brembo calipers |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. 2-pistons, 2-pads with Brembo caliper |
|
Diameter
|
230 mm (9.1 inches) |
|
Wheels
|
Forged Alluminium |
|
Physical measures and capacities |
|
Dry weight
|
169.0 kg (372.6 pounds) |
|
Power/weight ratio
|
0.5799 HP/kg |
|
Seat height
|
810 mm (31.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1110 mm (43.7 inches) |
|
Overall length
|
2050 mm (80.7 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Ground clearance
|
130 mm (5.1 inches) |
|
Wheelbase
|
1430 mm (56.3 inches) |
|
Fuel capacity
|
16.00 litres (4.23 US gallons) |
|
Reserve fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Other specifications |
|
Color options
|
Red/white/green |
|
Starter
|
Electric |
