2007 Bimota DB5 S

Bimota DB5 S 2007


2007 Bimota DB5 S specifications, pictures, reviews and rating

2007 Bimota DB5 S
2007 Bimota DB5 S. Picture credits - Bimota. Submit more pictures.

   Show big 2007 Bimota DB5 S picture More 2007 Bimota DB5 S images
2007 Bimota DB5 S
More pictures...

Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale
Insurance quotes
Tip a friend
List related bikes


General information
ModelBimota DB5 S
Year2007
CategorySport
RatingDo you know this bike?
Click here to rate it. We miss 2 votes to show the rating.
Engine and transmission
Displacement1079.0 ccm (65.84 cubic inches)
Engine typeTwin, two-stroke
Power95.0 HP (69.3 kW)) @ 7000 RPM
Torque103.0 Nm (10.5 kgf-m or 76.0 ft.lbs) @ 5500 RPM
Compression10.5:1
Bore x stroke98.0 x 71.5 mm (3.9 x 2.8 inches)
Valves per cylinder2
Fuel systemInjection. Electronic fule injection-45mm throttle body
Lubrication systemWet sump
Cooling systemAir
Gearbox6-speed
ClutchOil Bath Clutch, multi-disc
Chassis, suspension, brakes and wheels
Front suspensionUD Marzocchi TiN Coated Fork Full Adjustable (Pre-load, Compression, Rebound)
Rear suspensionMonoshock Extreme Tech Full Adjustable (Pre-load -External Hydraulic Device, Compression, Rebound
Front tire120/70-17
Rear tire180/55-17
Front brakesDouble disc. Double Ø320 mm Floating Discs Brembo, Radial Caliper Brembo 4-Pistons, 4-Pads
Diameter320 mm (12.6 inches)
Rear brakesSingle disc. Ø230 mm Disc Brembo, 2-Pistons, 2-Pads Brembo
Diameter230 mm (9.1 inches)
Physical measures and capacities
Dry weight189.0 kg (416.7 pounds)
Power/weight ratio0.5026 HP/kg
Front percentage of weight51.0
Rear percentage of weight49.0
Seat height810 mm (31.9 inches) If adjustable, lowest setting.
Overall height1230 mm (48.4 inches)
Overall length2045 mm (80.5 inches)
Overall width750 mm (29.5 inches)
Ground clearance170 mm (6.7 inches)
Wheelbase1440 mm (56.7 inches)
Fuel capacity16.00 litres (4.23 US gallons)
Other specifications
