| Bimota's profilation of this bike |
| The compact size of the bike brings to the rider both manageability and precision. |
|
General information |
|
Model
|
Bimota DB5 RE |
|
Year of manufacture
|
2013 |
|
Type
|
Sport |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
1078.0 ccm (65.78 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Engine details
|
Ducati 1100DS engine. L-twin. |
|
Output
|
98.0 HP (71.5 kW)) @ 8500 RPM |
|
Torque
|
105.0 Nm (10.7 kgf-m or 77.4 ft.lbs) @ 5500 RPM |
|
Top speed
|
230.0 km/h (142.9 mph) |
|
Compression
|
10.7:1 |
|
Bore x stroke
|
98.0 x 71.5 mm (3.9 x 2.8 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection. Bimota injection |
|
Fuel control
|
Desmodromic valve control |
|
Cooling system
|
Oil & air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Dry multiplate |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular chrome-molibdenum steel |
|
Rake (fork angle)
|
24.0° |
|
Trail
|
100 mm (3.9 inches) |
|
Front suspension
|
Upside-down fully adjustable forks |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Monoshock |
|
Rear wheel travel
|
120 mm (4.7 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
180/55-17 |
|
Front brakes
|
Single disc. Brembo, 4-pistons, 4-pads with radial Brembo calipers |
|
Diameter
|
298 mm (11.7 inches) |
|
Rear brakes
|
Single disc. 2-pistons, Bimota caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Forged Alluminium rims |
|
Physical measures and capacities |
|
Dry weight
|
169.0 kg (372.6 pounds) |
|
Power/weight ratio
|
0.5799 HP/kg |
|
Seat height
|
810 mm (31.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1110 mm (43.7 inches) |
|
Overall length
|
2050 mm (80.7 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Ground clearance
|
130 mm (5.1 inches) |
|
Wheelbase
|
1430 mm (56.3 inches) |
|
Fuel capacity
|
16.00 litres (4.23 US gallons) |
|
Other specifications |
|
Color options
|
Red/white/green |
