Big Dog's profilation of this bike |
Performance and style redefined. |
General information |
---|
Model: | Big Dog Wolf |
Year: | 2009 |
Category: | Custom / cruiser |
Price as new: | US$ 35900. MSRP depend on country, taxes, accessories, etc. |
Rating: | 3.1 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
Engine and transmission |
---|
Displacement: | 1976.0 ccm (120.58 cubic inches) |
Engine type: | V2, four-stroke |
Compression: | 9.9:1 |
Bore x stroke: | 108.0 x 108.0 mm (4.3 x 4.3 inches) |
Fuel system: | Injection. EFI |
Fuel control: | Overhead Valves (OHV) |
Cooling system: | Air |
Gearbox: | 6-speed |
Transmission type, final drive: | Belt |
Chassis, suspension, brakes and wheels |
---|
Frame type: | Steel |
Rake (fork angle): | 40.0° |
Trail: | 148 mm (5.8 inches) |
Front suspension: | 41 mm Telescopic Sleeved |
Front tyre: | 130/760-R23 |
Rear tyre: | 220/50-R20 |
Front brakes: | Single disc. 4-piston diff bore |
Rear brakes: | Single disc. 4-piston drive side |
Physical measures and capacities |
---|
Dry weight: | 349.0 kg (769.4 pounds) |
Seat height: | 622 mm (24.5 inches) If adjustable, lowest setting. |
Overall length: | 2604 mm (102.5 inches) |
Ground clearance: | 114 mm (4.5 inches) |
Wheelbase: | 1969 mm (77.5 inches) |
Fuel capacity: | 17.00 litres (4.49 gallons) |
Reserve fuel capacity: | 2.64 litres (0.70 gallons) |
Oil capacity: | 2.80 litres (0.18 quarts) |
Other specifications |
---|
Starter: | Electric |
Comments: | X-Wedge engine |
