| Big Dog's profilation of this bike |
| Rigid Frame with Surprising Comfort. |
| General information |
|---|
| Model: | Big Dog Ridgeback |
| Year: | 2009 |
| Category: | Custom / cruiser |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 1917.4 ccm (117.00 cubic inches) |
| Engine type: | V2, four-stroke |
| Compression: | 9.6:1 |
| Bore x stroke: | 104.8 x 111.1 mm (4.1 x 4.4 inches) |
| Fuel system: | Carburettor |
| Fuel control: | Overhead Valves (OHV) |
| Cooling system: | Air |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 39.0° |
| Trail: | 110 mm (4.4 inches) |
| Front suspension: | 41 mm telescopic |
| Rear suspension: | Rigid |
| Front tyre: | MH90-21 |
| Rear tyre: | 330/30-R17 |
| Front brakes: | Single disc. 4-piston diff bore |
| Rear brakes: | Single disc. 4-piston |
| Physical measures and capacities |
|---|
| Dry weight: | 308.4 kg (680.0 pounds) |
| Seat height: | 616 mm (24.3 inches) If adjustable, lowest setting. |
| Overall length: | 2718 mm (107.0 inches) |
| Ground clearance: | 114 mm (4.5 inches) |
| Wheelbase: | 2096 mm (82.5 inches) |
| Fuel capacity: | 16.65 litres (4.40 gallons) |
| Reserve fuel capacity: | 1.51 litres (0.40 gallons) |
| Oil capacity: | 2.80 litres (2.96 US quarts) |
| Other specifications |
|---|
| Starter: | Electric |
| Update specs | Report missing specs or required updates. |
