| Big Dog's profilation of this bike |
| Proven ProStreet Long and Low. |
|
General information |
|
Model name
|
Big Dog Mastiff |
|
Year model
|
2009 |
|
Type
|
Custom / cruiser |
| Price as new | US$ 27900. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.3 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
1917.0 ccm (116.98 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Compression
|
9.6:1 |
|
Bore x stroke
|
104.8 x 111.1 mm (4.1 x 4.4 inches) |
|
Fuel system
|
Carburettor. Optional electronic injection. |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
Electronic Single Fire |
|
Gearbox
|
6-speed |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
39.0° |
|
Trail
|
122 mm (4.8 inches) |
|
Front suspension
|
Telescopic |
|
Front tire
|
120/70-21 |
|
Rear tire
|
300/35-18 |
|
Front brakes
|
Single disc. 4-piston diff bore |
|
Rear brakes
|
Single disc. 4-piston |
|
Physical measures and capacities |
|
Dry weight
|
321.1 kg (708.0 pounds) |
|
Seat height
|
616 mm (24.3 inches) If adjustable, lowest setting. |
|
Overall length
|
2616 mm (103.0 inches) |
|
Ground clearance
|
102 mm (4.0 inches) |
|
Wheelbase
|
1969 mm (77.5 inches) |
|
Fuel capacity
|
17.78 litres (4.70 US gallons) |
|
Reserve fuel capacity
|
2.64 litres (0.70 US gallons) |
|
Oil capacity
|
2.80 litres (2.96 US quarts) |
|
Other specifications |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 09 Big Dog Mastiff discussion group or the general Big Dog discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Big Dog bike
|
Racing track capabilities for the 2009 Big Dog Mastiff:
 (50.2 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
