| Big Dog's profilation of this bike |
| Fat 250 rear tyre |
| General information |
|---|
| Model: | Big Dog K-9 250 |
| Year: | 2011 |
| Category: | Custom / cruiser |
| Price as new: | US$ 22595. MSRP depends on country, taxes, accessories, etc. |
| Rating: | 3.1 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 1819.1 ccm (111.00 cubic inches) |
| Engine type: | V2, four-stroke |
| Engine details: | 45 degree V-Twin |
| Compression: | 9.7:1 |
| Bore x stroke: | 104.8 x 111.1 mm (4.1 x 4.4 inches) |
| Fuel system: | Carburettor |
| Fuel control: | Overhead Valves (OHV) |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Driveline: | 6-speed direct drive. Chain primary drive - Spring Compensated |
| Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 42.0° |
| Trail: | 119 mm (4.7 inches) |
| Front suspension: | Telescopic fork |
| Front tire: | MH90-21 |
| Rear tire: | 250/40-R18 |
| Front brakes: | Single disc. 4-piston diff bore |
| Rear brakes: | Single disc. 4-piston |
| Physical measures and capacities |
|---|
| Dry weight: | 303.0 kg (668.0 pounds) |
| Seat height: | 622 mm (24.5 inches) If adjustable, lowest setting. |
| Overall length: | 2667 mm (105.0 inches) |
| Ground clearance: | 114 mm (4.5 inches) |
| Wheelbase: | 1981 mm (78.0 inches) |
| Fuel capacity: | 16.60 litres (4.39 gallons) |
| Reserve fuel capacity: | 1.50 litres (0.40 gallons) |
| Oil capacity: | 2.80 litres (2.96 US quarts) |
| Other specifications |
|---|
| Color options: | Black |
| Starter: | Electric |
| Electrical: | 310 CCA/Sealed AGM Battery. 32 Amp charging output. |
| Factory warranty: | 24 months unlimited milage |
