| General information |
|---|
| Model: | Big Dog K-9 |
| Year: | 2008 |
| Category: | Custom / cruiser |
| Rating: | 65.1 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 117.00 ccm (7.14 cubic inches) |
| Engine type: | V2, four-stroke |
| Fuel system: | Carburettor. Optional injection (EFI). |
| Fuel control: | Overhead Valves (OHV) |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 39.0° |
| Trail: | 110 mm (4.4 inches) |
| Front tyre: | MH90-21 |
| Rear tyre: | 300/35-18 |
| Front brakes: | Single disc. 4-piston |
| Rear brakes: | Single disc. 4-piston |
| Physical measures and capacities |
|---|
| Dry weight: | 318.0 kg (701.0 pounds) |
| Seat height: | 616 mm (24.3 inches) If adjustable, lowest setting. |
| Overall length: | 2,743 mm (108.0 inches) |
| Ground clearance: | 115 mm (4.5 inches) |
| Wheelbase: | 2,083 mm (82.0 inches) |
| Fuel capacity: | 16.65 litres (4.40 gallons) |
| Reserve fuel capacity: | 1.51 litres (0.40 gallons) |
| Other specifications |
|---|
| Further information |
|---|
