| General information |
|---|
| Model | Big Bear Choppers Athena 114 X-Wedge EFI |
| Year | 2010 |
| Category | Custom / cruiser |
| Price as new | US$ 37400. MSRP depends on country, taxes, accessories, etc. |
| Rating | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement | 1868.2 ccm (114.00 cubic inches) |
| Engine type | V2, four-stroke |
| Power | 97.0 HP (70.8 kW)) |
| Torque | 153.2 Nm (15.6 kgf-m or 113.0 ft.lbs) |
| Bore x stroke | 104.8 x 108.0 mm (4.1 x 4.3 inches) |
| Fuel system | Injection. S and S Closed-Loop Electronic Fuel Injection |
| Lubrication system | S and S High volume oil pump |
| Gearbox | 6-speed |
| Transmission type | Belt (final drive) |
| Exhaust system | Chrome Radius Tuned Exhaust |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Softail type |
| Rake (fork angle) | 40.0° |
| Trail | 95 mm (3.8 inches) |
| Front suspension | BBC Smooth Mount Hidden Axle |
| Rear suspension | Progressive |
| Rear wheel travel | 76 mm (3.0 inches) |
| Front tire | 90/80-21 |
| Rear tire | 300/80-18 |
| Front brakes | Single disc. PM. 4-piston calipers |
| Rear brakes | Single disc. BBC-PM 4-piston caliper BrakeDrive system |
| Physical measures and capacities |
|---|
| Dry weight | 317.5 kg (700.0 pounds) |
| Power/weight ratio | 0.3055 HP/kg |
| Seat height | 508 mm (20.0 inches) If adjustable, lowest setting. |
| Overall length | 2921 mm (115.0 inches) |
| Wheelbase | 2235 mm (88.0 inches) |
| Fuel capacity | 13.72 litres (3.62 US gallons) |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Other specifications |
|---|
| Color options | Gross Black, satin black, charcoal metallic, silver, black cherry, candy red, firecracker red, orange, electric blue. |
| Starter | Electric |
| Comments | 6-Speed Right-Side Drive Polished TransMision |
