| Beta's profilation of this bike |
| Attentive as ever to the needs of younger riders, Beta has enriched its trials range this year with a new REV-80: more adult and professional geometry and dimensions, and the usual emphasis on feel and confidence for riders who are just starting. |
|
General information |
|
Model name
|
Beta REV 80 |
|
Year of manufacture
|
2008 |
|
Type
|
Trial |
|
Rating
|
3.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
79.6 ccm (4.86 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Compression
|
14.7:1 |
|
Bore x stroke
|
48.0 x 44.0 mm (1.9 x 1.7 inches) |
|
Fuel system
|
Carburettor. Dell´ orto PHBG 21 |
|
Ignition
|
AET |
|
Lubrication system
|
mix with fuel 1,5 % (synthetic oil) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double wave aluminium beam |
|
Front tire
|
2.75-21 |
|
Rear tire
|
4-18 |
|
Front brakes
|
Single disc. 2-piston calipers |
|
Diameter
|
175 mm (6.9 inches) |
|
Rear brakes
|
Single disc. 2-piston calipers |
|
Diameter
|
150 mm (5.9 inches) |
|
Physical measures and capacities |
|
Dry weight
|
64.0 kg (141.1 pounds) |
|
Seat height
|
652 mm (25.7 inches) If adjustable, lowest setting. |
|
Overall height
|
1110 mm (43.7 inches) |
|
Overall length
|
1925 mm (75.8 inches) |
|
Overall width
|
815 mm (32.1 inches) |
|
Ground clearance
|
295 mm (11.6 inches) |
|
Wheelbase
|
1230 mm (48.4 inches) |
|
Fuel capacity
|
2.50 litres (0.66 US gallons) |
|
Reserve fuel capacity
|
0.50 litres (0.13 US gallons) |
|
Other specifications |
|
Modifications compared to previous model
|
New larger-diameter forks (ø 38 mm) with rebound adjustment and altered offset to increase rideability
New shockabsorber, derived from the one fitted to the larger-capacity machines, for even more professional and high-performance use
Swing-arm mounted on roller bearings for increased smoothness, reduced friction and greater reliability
Rationalisation and optimisation of the front end with a gain in terms of greater rigidity
Improved performance from brake system as a result of the latest changes:
new rear brake caliper (like the Rev-3 250), more powerful, more controllable and better protected from knocks
a new rear brake lever with improved operability
new master-cylinder and front caliper: opposed pistons and floating disc for even more controllable and precise action
New front disc cover of new design
New hubs with larger wheel-spindles in ergal: reduced weight combined with increased rigidity and a more professional look
New wheel-rims in aluminium, lighter and more rigid, and a move to tubeless tyres
New aluminium handlebar with cross-piece
New design of silencer, with optimised performance
New ø 21 mm Dell’Orto carburettor
New more precise and effective master-cylinder
New design for front mudguard
New colours and graphics to match the top-of-the-range Rev- |
