| Beta's profilation of this bike |
| Grown-up kids in search of more fun can rely on Rev-50: a real Rev built in a smaller scale. |
|
General moped information |
|
Model name
|
Beta Rev-50 |
|
Year model
|
2006 |
|
Type
|
Trial |
|
Rating
|
2.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.9 ccm (3.04 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Compression
|
15.2:1 |
|
Bore x stroke
|
40.0 x 39.7 mm (1.6 x 1.6 inches) |
|
Fuel system
|
Carburettor. Dell´ orto PHBG 19 |
|
Ignition
|
Electronic |
|
Lubrication system
|
Fuel mix 1.5% |
|
Cooling system
|
Liquid |
|
Gearbox
|
4-speed |
|
Clutch
|
Wet multi-disc |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel |
|
Front suspension
|
Hydraulic fork |
|
Front wheel travel
|
160 mm (6.3 inches) |
|
Rear suspension
|
Monoshock |
|
Rear wheel travel
|
146 mm (5.7 inches) |
|
Front brakes
|
Single disc |
|
Diameter
|
175 mm (6.9 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
150 mm (5.9 inches) |
|
Physical measures and capacities |
|
Dry weight
|
60.0 kg (132.3 pounds) |
|
Overall height
|
1070 mm (42.1 inches) |
|
Overall length
|
1850 mm (72.8 inches) |
|
Overall width
|
720 mm (28.3 inches) |
|
Ground clearance
|
300 mm (11.8 inches) |
|
Wheelbase
|
1210 mm (47.6 inches) |
|
Fuel capacity
|
2.50 litres (0.66 US gallons) |
|
Reserve fuel capacity
|
0.50 litres (0.13 US gallons) |
|
