| Beta's profilation of this bike |
| Thanks to the experience acquired on the racing fields, the new Rev-3 is already a landmark in world trial championship, where it takes part as the only Italian factory. |
| General information |
|---|
| Model | Beta Rev-3 125 |
| Year | 2006 |
| Category | Trial |
| Rating | 3.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 124.0 ccm (7.57 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Compression | 14.0:1 |
| Bore x stroke | 54.0 x 54.0 mm (2.1 x 2.1 inches) |
| Fuel system | Carburettor. Mikuni VM26/208 |
| Ignition | Electronic |
| Lubrication system | Fuel mix 1.5% |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-disc clutch with cush-drive rubber |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Aluminium |
| Front suspension | Hydraulic fork |
| Front wheel travel | 185 mm (7.3 inches) |
| Rear suspension | Monoshock |
| Rear wheel travel | 165 mm (6.5 inches) |
| Front brakes | Single disc |
| Diameter | 185 mm (7.3 inches) |
| Rear brakes | Single disc |
| Diameter | 175 mm (6.9 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 71.0 kg (156.5 pounds) |
| Overall length | 1990 mm (78.3 inches) |
| Overall width | 850 mm (33.5 inches) |
| Ground clearance | 310 mm (12.2 inches) |
| Wheelbase | 1310 mm (51.6 inches) |
| Fuel capacity | 4.20 litres (1.11 US gallons) |
| Other specifications |
|---|
