| Beta's profilation of this bike |
| The bike sports a 16” front wheel and a 14” rear, so even the smallest rider can touch the ground easily.
Compared with previous versions, the handlebar and foot controls have been modified to make them more practical and easier for children to recognize and use. |
| General moped information |
|---|
| Model | Beta Minitrial |
| Year | 2010 |
| Category | Trial |
| Rating | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement | 49.0 ccm (2.99 cubic inches) |
| Engine type | Single cylinder, two-stroke |
| Compression | 13.9:1 |
| Bore x stroke | 39.5 x 40.0 mm (1.6 x 1.6 inches) |
| Fuel system | Carburettor. Dell´Orto SHA 14 - 12L |
| Ignition | Electronic Selettra |
| Lubrication system | Mix with fuel 1,5% with synthetic oil |
| Cooling system | Air |
| Gearbox | Automatic |
| Transmission type | Chain (final drive) |
| Clutch | Automatic centrifugal wet clutch |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Steel tubing |
| Front suspension | Mechanical fork with ø30 mm shaft |
| Front tire | 2.5-16 |
| Rear tire | 2.5-14 |
| Front brakes | Expanding brake (drum brake). Mechanical drive drum |
| Diameter | 66 mm (2.6 inches) |
| Rear brakes | Expanding brake (drum brake). Mechanical drive drum |
| Diameter | 90 mm (3.5 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 42.5 kg (93.7 pounds) |
| Seat height | 570 mm (22.4 inches) If adjustable, lowest setting. |
| Overall height | 940 mm (37.0 inches) |
| Overall length | 1530 mm (60.2 inches) |
| Ground clearance | 255 mm (10.0 inches) |
| Wheelbase | 1020 mm (40.2 inches) |
| Fuel capacity | 2.00 litres (0.53 US gallons) |
| Reserve fuel capacity | 0.30 litres (0.08 US gallons) |
| Other specifications |
|---|
| Color options | Black/white |
